60 Amp Non-fused Disconnect Pull Out
The U3802 AC Disconnect from Milbank is the perfect addition to go along with all your HVAC needs. Are you installing any heat pumps this summer? You'll want to have these handy to pair with your HVAC Installations!
KEY FEATURES: Disconnect Switch, Non-Fusible. Voltage Rating: 240 VAC. Amperage Rating: 60 AMP, 2 Poles, Surface Mount. Dimensions: 5 IN W x 2-1/2 IN D x 7-1/2 IN HT. Material: Painted Steel Housing. Wire Size: 14 - 2 AWG (Cu), 12 - 2 AWG (Al), 1 Phase, NEMA 3R Enclosure. Horsepower: 10 HP, Fusible No, Pull-Out Connection. Operating Temperature Range: 60/75 DEG C. Interrupt Rating: 10 KAMP.
