Ideal Industries

30-1039J - In-Sure® Push-In Wire Connector, Model 39 3-Port Blue, Jar of 150

Category Wire Connectors
Picture of 30-1039J - In-Sure® Push-In Wire Connector, Model 39 3-Port Blue, Jar of 150 Picture of 30-1039J - In-Sure® Push-In Wire Connector, Model 39 3-Port Blue, Jar of 150
Picture of 30-1039J - In-Sure® Push-In Wire Connector, Model 39 3-Port Blue, Jar of 150 Picture of 30-1039J - In-Sure® Push-In Wire Connector, Model 39 3-Port Blue, Jar of 150
Picture of 30-1039J - In-Sure® Push-In Wire Connector, Model 39 3-Port Blue, Jar of 150 Picture of 30-1039J - In-Sure® Push-In Wire Connector, Model 39 3-Port Blue, Jar of 150
Picture of 30-1039J - In-Sure® Push-In Wire Connector, Model 39 3-Port Blue, Jar of 150 Picture of 30-1039J - In-Sure® Push-In Wire Connector, Model 39 3-Port Blue, Jar of 150
Picture of 30-1039J - In-Sure® Push-In Wire Connector, Model 39 3-Port Blue, Jar of 150 Picture of 30-1039J - In-Sure® Push-In Wire Connector, Model 39 3-Port Blue, Jar of 150
Ideal Industries

30-1039J - In-Sure® Push-In Wire Connector, Model 39 3-Port Blue, Jar of 150

Item Code: 757274
Category Wire Connectors
Manufacturer Ideal Industries
Manufacturer Ref 30-1039J
Minimum order quantity 150

Owners User Manual
RoHS
Call for Availability
Add to Favorites
Compare

Description

Strip, push, connect – the fastest way to make a connection.The In-Sure® Push-In Wire Connector is perfect for residential, light commercial, lighting retrofit, and pre-fab wiring systems, or any other branch circuit wiring application where a traditional twist-on wire connector would be used. Simply push the wire in – the low insertion force makes it easy.The color-coded shell allows for quick identification of port configuration while the clear polycarbonate housing allows for visual verification of every connection. The ergonomic design is easier to grip which means more comfortable push-in connections. The compact size makes for easy installations in even the tightest spots or shallow boxes, and the tough, flame-retardant shell stands up to the harshest environments.UL Listed, CSA Certified, and rated to 600V – the In-Sure® saves time and improves productivity while perfecting connections.

Specifications

Weight

1.4lb

Height

2.75mm

Width

4.25mm

Length

7.5mm

Brand

Ideal Industries

Category

Wire Connectors

Color

Blue

Dimensions

0.78 in L x 0.86 in W x 0.45 in H

Finish

Tin Plated

Material

Nylon/Polycarbonate

Specifications

3 Ports, 3/8 to 1/2 in Strip Length

Temperature Rating

221 deg F

Voltage Rating

600 V AC

Wire Size

14 to 10 AWG, 12 to 10 AWG, 14 to 10 AWG

Wire Type

Solid/Stranded/Tin-Bonded
