Ideal Industries

61-657 - Ideal Electrical 61-657 - Dual Range 12-1000V Ac Ncvt With Flashlight

Category Testers & Accessories
Picture of 61-657 - Ideal Electrical 61-657 - Dual Range 12-1000V Ac Ncvt With Flashlight Picture of 61-657 - Ideal Electrical 61-657 - Dual Range 12-1000V Ac Ncvt With Flashlight
Picture of 61-657 - Ideal Electrical 61-657 - Dual Range 12-1000V Ac Ncvt With Flashlight Picture of 61-657 - Ideal Electrical 61-657 - Dual Range 12-1000V Ac Ncvt With Flashlight
Picture of 61-657 - Ideal Electrical 61-657 - Dual Range 12-1000V Ac Ncvt With Flashlight Picture of 61-657 - Ideal Electrical 61-657 - Dual Range 12-1000V Ac Ncvt With Flashlight
Picture of 61-657 - Ideal Electrical 61-657 - Dual Range 12-1000V Ac Ncvt With Flashlight Picture of 61-657 - Ideal Electrical 61-657 - Dual Range 12-1000V Ac Ncvt With Flashlight
Picture of 61-657 - Ideal Electrical 61-657 - Dual Range 12-1000V Ac Ncvt With Flashlight Picture of 61-657 - Ideal Electrical 61-657 - Dual Range 12-1000V Ac Ncvt With Flashlight
Ideal Industries

61-657 - Ideal Electrical 61-657 - Dual Range 12-1000V Ac Ncvt With Flashlight

Item Code: 1190251
Category Testers & Accessories
Manufacturer Ideal Industries
Manufacturer Ref 61-657

Catalog
Owners User Manual
Specification Sheet
Warranty Information
Call for Availability
Add to Favorites
Compare

Description

The IDEAL® 61-657 is Cat IV 1000 VAC, IP67 UL Listed, dual range non-contact Voltage Tester that automatically detects and indicates the presence of voltages between 12 to 1000 VAC (Low Range) and 50 to 1000 VAC (High Range) with the push of a button. The tester can sustain a drop from 6.6 ft (2 m) and provides non-contact detection of voltage through an antenna enclosed in plastic at the tip of the tester which senses the presence of the electromagnetic field present around live conductors. The tip is illuminated by a green LED when powered on and switches to a red flashing LED, and audible beep that increase in frequency as the voltage level increases. The tester is powered by two 1.5 V AAA batteries and features an in tip LED flash light, an audible disable function, a lanyard tie-off point, an auto power off function and a low battery indication.

Specifications

Weight

0.3lb

Height

2.96mm

Width

8.42mm

Length

1.72mm

Battery

(2) 1.5 V AAA Alkaline

Brand

Ideal Industries

Category

TESTERS & ACCESSORIES

Dimensions

6.4 in L x 1 in W x 1.2 in H

Display Type

Led

Distance Range

6.6 ft

Enclosure Type

IP67

Environmental Conditions

32 to 104 deg F Operating, 14 to 122 deg F Storage

Frequency Rating

50/60 Hz

Light Source

Led

Material

Plastic

Maximum Working Voltage

12 to 1000 V AC

Power Supply

Battery

Type

Non-Contact
