MC144FABEWE - MC Glide Fire Alarm 14/4, Blue/White, 250' Coil
Description
Specifications
48mm
Atkore
USA
US
FA CBL REEL 600V TYPE MC/300V TYPE FPLP
Cable System
Technically equivalent and economically superior to traditional raceway and wire installations
Red Steel Armor with optional phase ID painted directly onto the armor for added identification
Easier Pulls. U.S. Patented armor profile is designed to reduce fatigue on your workers when pulling cable through metal studs and ceilings
Time Savings
From the first pull, installing MC Glide Tuff will be smoother, faster, and easier to work with
Minimize Damage
Less resistance means less opportunity for cable hang ups, that may knock down studs or damage dry wall
No need for new tools
Works with the same tools, fittings and supports as traditional MC Cables
The new profile of MC Glide tends to lay flatter than legacy MC cable, notably reducing curling or bend memory issues
Addditional stripe color corresponding to conductor color is added to armor
Atkore
48.0000
IN
1
General Wire
CU Interlocked Steel Armor Cables - Teck
Conductor Size
AWG
14
Conductor Type
Solid Copper
Insulation Material
THHN/THWN
Length
Ft
250
Number of Conductors
4
Outside Diameter
IN
0.49
Packaging Type
Reel
Voltage Rating
V
600/300
