PS30AC2-I - Industrial Extra Heavy Duty Specification Grade Switch, Ivory
Description
Specifications
0.22lb
4.31mm
1.81mm
2.19mm
For industrial uses such as health care, education and institutional applications
Pass & Seymour
USA
MX
SWITCH TGL 120/277VAC 30A 2HP 2 WALL SCR
External screw-pressure-plate back and side wired
Accepts 14 - 10 AWG copper or copper-clad conductors
Heavy-gauge one-piece copper alloy contact arm virtually eliminates contact bounce
Cam controls fast 'make and positive break' to minimize arcing
Heavy-duty bumper pads for quiet operation
High strength thermoplastic polycarbonate toggle
Back body made of glass-reinforced nylon
Locking support provides resistance to face and back body separation
Oversized silver alloy contacts for long life and better heat dissipation
Grounding terminal is standard
Shallow design for ease of installation
Strap nickel-plated steel with integral ground
Auto-ground clip assures positive ground
For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here
Legrand
4.3100
IN
2.1900
IN
1
0.2200
LB
1.8100
IN
Pass & Seymour
General Purpose Switches
Actuator
Cam/Spring/Toggle
Power Rating
HP
2
Terminal Type
Screw
Type
Heavy Duty
Voltage Rating
V AC
120/277
Amperage Rating
A
30
Color
Ivory
Dimensions
3.3 in H x 1.32 in W x 1.073 in D
Environmental Conditions
-40 to 115 deg C Temperature
Material
Nylon
Mounting
Wall
Number Of Poles
2
Operating Cycles
Cycles
50000
