Description
Specifications
0.33lb
4.31mm
2mm
2.12mm
Healthcare, Education, Airports, Retail, Hospitality/Lodging, Office, Institutional and Multiple Dwelling Applications
Pass & Seymour
USA
VN
RECEPTACLE CHARGING USB 15 A 125 VAC 2
Protects children - patented shutter system helps prevent improper insertion of foreign objects
Conducts an automatic test every three seconds, ensuring it's always ready to protect
If the device fails the test, the indicator light flashes to signal that the GFCI should be replaced
It also has our proven SafeLock Protection feature - if critical components are damaged and protection is lost, power to the receptacle is disconnected
High-impact-resistant thermoplastic construction with tri-drive terminal screws
Legrand
4.3100
IN
2.1200
IN
1
0.3300
LB
2.0000
IN
Pass & Seymour
Combination Devices
Color
White
USB Rating
A
6
USB Type
Type-A USB 2.0/C
Wire Size
AWG
14 to 10
Wiring Method
Back/Side Wire
Connection
Screw
Electrical Ratings
15 A, 125 V AC
Environmental Conditions
-40 to 60 deg C Operating Temperature
Grade
Commercial/Specification
Material
Nylon/Polycarbonate
Size
2.69 in H x 1.74 in W x 1.67 in D
Type
Ultra-Fast
USB Quantity
2
