TR5362CHW - 20A 125V Hard Use Spec-Grade Tamper-Resistant Half-Controlled Plug Load Decorator Duplex Receptacle, White
Description
Specifications
0.2
4.25
1.25
1.81
Pass & Seymour
USA
MX
RECEPTACLE BL STR 125VAC 20A WHT 5-20R
Can be wired to any number of system-based or stand-alone plug load control solutions
0.032 in thick, brass, triple-wipe power contacts for lasting retention
Permanent controlled receptacle markings using abrasion resistant ink
Two drive screws anchor strap to back body and face where abrupt removal torque is strongest
Tri-drive brass-plated terminal screws
Two back-wire holes for more wiring flexibility
Strap tabs wrap around face to prevent strap from separating from face and back body
CH Version Only, Split circuit tab broken at the factory, allowing half of the receptacle to be controlled
Legrand
4.2500
IN
1.8100
IN
1
0.2000
LB
1.2500
IN
Pass & Seymour
RECEPTACLES & SURGE PROTECTORS
Amperage Rating
A
20
Voltage Rating
V AC
125
Color
White
Dimensions
0.78 in L x 1.322 in W x 3.281 in H
Grade
Commercial/Specification
Material
Nylon/PVC
NEMA Rating
5-20R
Temperature Rating
deg C
-40 To 60
Terminal Type
Back/Side Wire
Type
Duplex Half Controlled Plug Load Controllable
