NUVO® by SATCO

65/770R3 - Wattage 80W/100W/120W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish

Category Miscellaneous
Picture of 65/770R3 - Wattage 80W/100W/120W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish Picture of 65/770R3 - Wattage 80W/100W/120W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish
Picture of 65/770R3 - Wattage 80W/100W/120W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish Picture of 65/770R3 - Wattage 80W/100W/120W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish
Picture of 65/770R3 - Wattage 80W/100W/120W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish Picture of 65/770R3 - Wattage 80W/100W/120W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish
Picture of 65/770R3 - Wattage 80W/100W/120W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish Picture of 65/770R3 - Wattage 80W/100W/120W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish
Picture of 65/770R3 - Wattage 80W/100W/120W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish Picture of 65/770R3 - Wattage 80W/100W/120W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish
NUVO® by SATCO

65/770R3 - Wattage 80W/100W/120W and CCT Selectable 3K/4K/5K LED UFO High Bay - 120-347 Volt - Black Finish

Item Code: 1228655
Category Miscellaneous
Manufacturer SATCO PRODUCTS
Manufacturer Ref 65-770R3

Document
Document
Call for Availability
Add to Favorites
Compare

Description

SATCO|NUVO's 65-770R3 Round High Bay Field Selectable fixture in a black finish, offers an energy efficient and low-maintenance alternative to traditional HID fixtures. This luminary is field selectable, giving users the flexibility to choose from three wattage and three CCT options during installation. The fixture is constructed with a durable die-cast aluminum housing and an IK08 impact-rated polycarbonate lens. Featuring 6kV surge protection, 120V-347V range voltage and NEMA 4X (IP65) wet location ratings, this high bay is resilient in various commercial environments. Compatible with a wide variety of accessories (sold separately) this fixture can be customized to accommodate a multitude of lighting needs.

Specifications

Weight

5.72

Height

4.92

Width

11.81

Length

11.81

AD All Features

CCT and Wattage Selectable

AD Brand (Description)

NUVO® by SATCO

AD Country

USA

AD Country Of Origin

VN

AD Gtin

10045923651899

AD Includes

Locking Hanging Hook, 6 Foot Whip and Integrated Bulb

AD Invoice Description

INDOOR H BAY FXTR INTEGRATED LED

AD Item Features 01

CCT and Wattage Selectable

AD Item Features 02

Integrated Sensor Port

AD Item Features 03

EM Battery Backup Capable

AD Item Features 04

6 Foot Supply and Low Voltage Whips

AD Item Features 05

6kV Surge Protection

AD Manufacturer (Description)

SATCO PRODUCTS

AD Package Height

4.9200

AD Package Height UOM

IN

AD Package Length

11.8100

AD Package Length UOM

IN

AD Package Quantity

1

AD Package Weight

5.7200

AD Package Weight UOM

LB

AD Package Width

11.8100

AD Package Width UOM

IN

Brand

Satco

Category

Miscellaneous

Spec 1 Attribute

Ballast Type

Spec 1 Attribute Value

0 to 10 V Dimmable

Spec 10 Attribute

Lamp Wattage

Spec 10 Attribute UOM

W

Spec 10 Attribute Value

80, 100, 120

Spec 11 Attribute

Lens Type

Spec 11 Attribute Value

Polycarbonate

Spec 12 Attribute

Lumens

Spec 12 Attribute UOM

Lumens

Spec 12 Attribute Value

11840 to 18600

Spec 13 Attribute

Voltage Rating

Spec 13 Attribute UOM

V

Spec 13 Attribute Value

120 to 347

Spec 2 Attribute

Color Rendering Index (CRI)

Spec 2 Attribute Value

80

Spec 3 Attribute

Color Temperature

Spec 3 Attribute UOM

K

Spec 3 Attribute Value

3000, 4000, 5000

Spec 4 Attribute

Dimensions

Spec 4 Attribute Value

7.3 in H x 11 in W

Spec 5 Attribute

Enclosure Type

Spec 5 Attribute Value

IP65

Spec 6 Attribute

Fixture Wattage

Spec 6 Attribute UOM

W

Spec 6 Attribute Value

80, 100, 120

Spec 7 Attribute

Housing Finish

Spec 7 Attribute Value

Black

Spec 8 Attribute

Housing Material

Spec 8 Attribute Value

Die-Cast Aluminum

Spec 9 Attribute

Lamp Base Type

Spec 9 Attribute Value

Integrated
