SATCO®

11.5/13/15 Wattage Selectable T8 U-Bend LED - 30K/35K/40K/50K/65K CCT Selectable - 6-Inch - Frost Finish - 120-277 Range Voltage

Category Miscellaneous
Picture of 11.5/13/15 Wattage Selectable T8 U-Bend LED - 30K/35K/40K/50K/65K CCT Selectable - 6-Inch - Frost Finish - 120-277 Range Voltage Picture of 11.5/13/15 Wattage Selectable T8 U-Bend LED - 30K/35K/40K/50K/65K CCT Selectable - 6-Inch - Frost Finish - 120-277 Range Voltage
Picture of 11.5/13/15 Wattage Selectable T8 U-Bend LED - 30K/35K/40K/50K/65K CCT Selectable - 6-Inch - Frost Finish - 120-277 Range Voltage Picture of 11.5/13/15 Wattage Selectable T8 U-Bend LED - 30K/35K/40K/50K/65K CCT Selectable - 6-Inch - Frost Finish - 120-277 Range Voltage
Picture of 11.5/13/15 Wattage Selectable T8 U-Bend LED - 30K/35K/40K/50K/65K CCT Selectable - 6-Inch - Frost Finish - 120-277 Range Voltage Picture of 11.5/13/15 Wattage Selectable T8 U-Bend LED - 30K/35K/40K/50K/65K CCT Selectable - 6-Inch - Frost Finish - 120-277 Range Voltage
Picture of 11.5/13/15 Wattage Selectable T8 U-Bend LED - 30K/35K/40K/50K/65K CCT Selectable - 6-Inch - Frost Finish - 120-277 Range Voltage Picture of 11.5/13/15 Wattage Selectable T8 U-Bend LED - 30K/35K/40K/50K/65K CCT Selectable - 6-Inch - Frost Finish - 120-277 Range Voltage
Picture of 11.5/13/15 Wattage Selectable T8 U-Bend LED - 30K/35K/40K/50K/65K CCT Selectable - 6-Inch - Frost Finish - 120-277 Range Voltage Picture of 11.5/13/15 Wattage Selectable T8 U-Bend LED - 30K/35K/40K/50K/65K CCT Selectable - 6-Inch - Frost Finish - 120-277 Range Voltage
SATCO®

11.5/13/15 Wattage Selectable T8 U-Bend LED - 30K/35K/40K/50K/65K CCT Selectable - 6-Inch - Frost Finish - 120-277 Range Voltage

Item Code: 1240289
Category Miscellaneous
Manufacturer SATCO PRODUCTS
Manufacturer Ref S18413

Document
Document
Call for Availability
Add to Favorites
Compare

Description

SATCO|NUVO's S18413 LED filament U-Bend lamp with 6-inch leg spacing, delivers versatile and efficient lighting solutions for a range of applications. This lamp consumes significantly less energy than its fluorescent counterpart and features a much longer lifespan, leading to reduced maintenance costs. With selectable CCT and wattage, users can perfectly tailor the light output to their needs. The Type A/B ballast bypass compatibility provides flexibility for easy installation with or without the existing ballast, enhancing convenience and long-term energy savings. Constructed with full glass housing, this lamp resists aging, yellowing, and bending, ensuring lasting durability. It is mercury-free, environmentally friendly, and NSF® approved, making it safe for food service and healthcare environments. Retrofit your fluorescent U-Bend lamps with our LED U-Bend lamp and start saving today.

Specifications

Weight

0.76

Height

1.22

Width

1.22

Length

23.03

AD All Features

CCT and Wattage Selectable

AD Application

Solutions for a range of applications

AD Brand (Description)

Satco®

AD Country

USA

AD Country Of Origin

CN

AD Document Caption 1

Specification Sheet

AD Document Caption 2

Instruction/Installation Manual

AD Gtin

10045923184137

AD Invoice Description

LED - U-BT 11.5, 13, 15W 50W

AD Item Features 01

CCT and Wattage Selectable

AD Item Features 02

Type A/B Ballast Bypass

AD Item Features 03

Single and Double Ended Wiring

AD Item Features 04

6 in Leg Spacing

AD Keywords

S18413 SATCO Dimmable U Bend LED, 11.5, 13, 15 W, 50 W Incandescent Equivalent, G13 Lamp Base, T8 Shape, 1800, 2000, 2200 Lumens ; SATCO ; S18413 ; 045923184130 ; LED - U-Bent

AD Manufacturer (Description)

SATCO PRODUCTS

AD Package Height

1.2200

AD Package Height UOM

IN

AD Package Length

23.0300

AD Package Length UOM

IN

AD Package Quantity

1

AD Package Weight

0.7600

AD Package Weight UOM

LB

AD Package Width

1.2200

AD Package Width UOM

IN

AD Part Number Keywords

S18413 ; 045923184130 ; 45923184130 ; 04592318413 ; 10045923184137

Brand

Satco

Spec 1 Attribute

Amperage Rating

Spec 1 Attribute UOM

A

Spec 1 Attribute Value

0.19

Spec 10 Attribute

Lamp Base Type

Spec 10 Attribute Value

G13

Spec 11 Attribute

Lamp Finish

Spec 11 Attribute Value

Frost

Spec 12 Attribute

Lumens

Spec 12 Attribute UOM

Lumens

Spec 12 Attribute Value

1800, 2000, 2200

Spec 13 Attribute

Series

Spec 13 Attribute Value

Satco

Spec 14 Attribute

Shape

Spec 14 Attribute Value

T8

Spec 15 Attribute

Type

Spec 15 Attribute Value

Dimmable

Spec 16 Attribute

Voltage Rating

Spec 16 Attribute UOM

V

Spec 16 Attribute Value

120 To 277

Spec 17 Attribute

Wattage

Spec 17 Attribute UOM

W

Spec 17 Attribute Value

11.5, 13, 15

Spec 2 Attribute

Ballast Type

Spec 2 Attribute Value

Type A/B Bypass

Spec 3 Attribute

Beam Angle

Spec 3 Attribute UOM

deg

Spec 3 Attribute Value

210

Spec 4 Attribute

Color

Spec 4 Attribute Value

Soft White to Daylight

Spec 5 Attribute

Color Rendering Index (CRI)

Spec 5 Attribute Value

80

Spec 6 Attribute

Color Temperature

Spec 6 Attribute UOM

K

Spec 6 Attribute Value

3000, 3500, 4000, 5000, 6500

Spec 7 Attribute

Dimensions

Spec 7 Attribute Value

1.22 in H x 1.22 in W x 23.03 in L

Spec 8 Attribute

Filament

Spec 8 Attribute Value

Led

Spec 9 Attribute

Incandescent Equivalent

Spec 9 Attribute UOM

W

Spec 9 Attribute Value

50
