CM PDT 10 - LITH CM PDT 10 Ceiling Mount Sensor
Description
Specifications
0.54lb
4.4mm
2.5mm
4.5mm
184CGY
Cafeteria, Classroom, Closet/Storage Room, Conference Room, Examination Room, Hospital, Kitchen, Library, Living Area, Locker Room, Manufacturing, Open Office, Patient Room, Private Office, Restroom and Retail Applications
Sensor Switch
Grainger - 6DXE0
USA
MX
184CGY
Specification Sheet
Instruction/Installation Manual
00745975808243
10600858
SENSOR OCCUPANCY 12 TO 24VAC/VDC PDT 4MA
The Sensor Switch CM PDT 10 large motion ceiling mount sensor combines a low voltage sensor into a low profile design, making it perfect to mount directly to a ceiling tile or metallic grid
UNIQUE FEATURE - For rooms with obstructions, these sensors offer Passive Dual Technology (PDT), which combines Microphonics noise detection and passive infrared (PIR) motion detection
LAMP - 100 hr lamp burn-in timer mode
RADIAL COVERAGE - 24 foot radial coverage when mounted at 9 ft, 7-15 foot mounting heights provide 16-36 ft radial coverage
SENSORS - Up to 14 sensors per power pack
CM PDT 10 CM PDT Low Voltage Occupancy Sensor, 12 to 24 V AC/DC, PDT Sensor, 28 ft Coverage, 360 deg Viewing ; Sensor Switch ; CM PDT 10 ; 184CGY ; 10600858 ; 745975808243 ; Ceiling Mount Occupancy Sensors
Acuity Brands
4.4000
IN
4.5000
IN
1
0.5400
LB
2.5000
IN
CM PDT 10 ; CMPDT10 ; 184CGY ; 10600858 ; 13090459 ; 745975808243 ; 74597580824 ; 00745975808243
Own Brand
LIGHTING OCCUPANCY SENSORS
Amperage Rating
MA
4
Temperature Rating
deg C
-10 To 71
Time Delay
30 s to 20 min
Type
Low Voltage
Viewing Angle
deg
360
Voltage Rating
V AC/DC
12 to 24
Color
Matte White
Connection Type
Wired
Coverage
Ft
28
Dimensions
4.55 in Dia x 1.55 in D
Material
Plastic
Mounting Type
Ceiling
Sensor Type
PDT
Series
CM PDT
