CM PDT 9 - LITH CM PDT 9 Ceiling Mount Sensor,
Description
Specifications
0.54lb
4.4mm
2.5mm
4.5mm
184CGX
Cafeteria, Classroom, Closet/Storage Room, Conference Room, Examination Room, Hospital, Kitchen, Living Area, Locker Room, Open Office, Patient Room, Private Office and Restroom Applications
Sensor Switch™
Grainger - 6DXE1
USA
MX
184CGX
Catalog
Specification Sheet
Instruction/Installation Manual
00745975808229
10600857
SENSOR OCCUPANCY 12 TO 24VAC/VDC PDT 4MA
The CM 9 small motion ceiling mount sensor combines a low voltage sensor into a sleek, low profile design, making it perfect to mount directly to a ceiling tile or metallic grid
For rooms with obstructions, these sensors offer Passive Dual Technology (PDT), which adds Microphonics detection to passive infrared (PIR) detection
Enjoy the flexibility and convenience of programming sensor settings with your smartphone using the Sensor Switch Mobile App through camera flash programming
360 deg conical shaped pattern provides 12 ft radial coverage when mounted to standard 9 ft ceiling, 8 to 15 ft mounting heights provide 10 to 20 ft radial coverage, up to 14 sensors per power pack
Best choice for small motion (e.g. hand movements) detection
CM PDT 9 CM PDT Low Voltage Occupancy Sensor, 12 to 24 V AC/DC, PDT Sensor, 12 ft Coverage, 360 deg Viewing ; Sensor Switch ; CM PDT 9 ; 184CGX ; 10600857 ; 745975808229 ; Ceiling Mount Occupancy Sensors
Acuity Brands
4.4000
IN
4.5000
IN
1
0.5400
LB
2.5000
IN
CM PDT 9 ; CMPDT9 ; 184CGX ; 10600857 ; 13090458 ; 745975808229 ; 74597580822 ; 00745975808229
Own Brand
LIGHTING OCCUPANCY SENSORS
Amperage Rating
MA
4
Temperature Rating
deg C
-10 To 71
Time Delay
30 s to 20 min
Type
Low Voltage
Viewing Angle
deg
360
Voltage Rating
V AC/DC
12 to 24
Color
Matte White
Coverage
Ft
12
Dimensions
4.55 in Dia x 1.55 in D
Material
Plastic
Mounting Type
Ceiling
Response Frequency
MHz
902
Sensor Type
PDT
Series
CM PDT
