CMR 9 - LITH CMR 9 Ceiling Mount Sensor, Sm
Description
Specifications
0.51lb
4.6mm
4.41mm
4.53mm
https://image.img360.acuitybrands.com/Downlighting/CMR/9/9.spin
184CH2
Automotive and Parking, Education, Government, Healthcare, Hospitality, Manufacturing, Offices and Banks, Power and Gas, Religious, Residential, Retail, Roadways, Bridges and Tunnels, Sports and Recreation, Transportation, Warehouses Applications
Sensor Switch
Grainger - 6DXE4
USA
MX
184CH2
Specification Sheet
Instruction/Installation Manual
00745975808281
10600861
SENSOR OCCUPANCY MT CEILING 120/277VAC
The SensorSwitch CMR 9 small motion, line voltage ceiling mount occupancy sensor offers a low profile design, making it perfect to mount directly to a ceiling tile or metallic grid
With a variety of lens options, CMR sensors utilize 100 Percent passive Infrared detection and is powered directly from line voltage without the need of a power pack
With either programing method, the user can change time delay
ENERGRY SAVINGS - Self-contained relay (no power pack needed)
DIMMING - Enjoy the flexibility and convenience of programming sensor settings with your smartphone using the SensorSwitch VLP Mobile App through camera flash programming
MOUNTING - 12 ft radial coverage when mounted to standard 9 ft ceiling, 8-15 ft mounting heights provide 10-20 ft radial coverage
FEATURE - Best choice for small motion detection
BATTERY - 100 hr lamp burn-in timer mode
CMR 9 CM Series Line Voltage Ceiling Mount Occupancy Sensor, 120/277 V AC, Passive Infrared Sensor, 12 ft Coverage, 360 deg Viewing ; Sensor Switch ; CMR 9 ; 184CH2 ; 10600861 ; 745975808281 ; Ceiling Mount Occupancy Sensors
Acuity Brands
4.6000
IN
4.5300
IN
1
0.5100
LB
4.4100
IN
CMR 9 ; CMR9 ; 184CH2 ; 10600861 ; 13090462 ; 745975808281 ; 74597580828 ; 00745975808281
https://youtu.be/FOsOlRaDNpA
Own Brand
LIGHTING OCCUPANCY SENSORS
Amperage Rating
MA
16
Series
CM Series
Temperature Rating
deg F
14 To 160
Time Delay
30 s to 30 min
Type
Line Voltage
Viewing Angle
deg
360
Voltage Rating
V AC
120/277
Color
Matte White
Connection Type
Wired
Coverage
Ft
12
Dimensions
4.55 in Dia x 1.55 in D
Material
Plastic
Mounting Type
Ceiling
Response Frequency
HZ
50/60
Sensor Type
Passive Infrared
