2S46F - Transformer, buck boost, encapsulated, 2kVA, 1 phase, 120x240V primary, 16/32V secondary, NEMA 3R, 115C rise

Category Miscellaneous
Picture of 2S46F - Transformer, buck boost, encapsulated, 2kVA, 1 phase, 120x240V primary, 16/32V secondary, NEMA 3R, 115C rise Picture of 2S46F - Transformer, buck boost, encapsulated, 2kVA, 1 phase, 120x240V primary, 16/32V secondary, NEMA 3R, 115C rise
Picture of 2S46F - Transformer, buck boost, encapsulated, 2kVA, 1 phase, 120x240V primary, 16/32V secondary, NEMA 3R, 115C rise Picture of 2S46F - Transformer, buck boost, encapsulated, 2kVA, 1 phase, 120x240V primary, 16/32V secondary, NEMA 3R, 115C rise
Picture of 2S46F - Transformer, buck boost, encapsulated, 2kVA, 1 phase, 120x240V primary, 16/32V secondary, NEMA 3R, 115C rise Picture of 2S46F - Transformer, buck boost, encapsulated, 2kVA, 1 phase, 120x240V primary, 16/32V secondary, NEMA 3R, 115C rise
Picture of 2S46F - Transformer, buck boost, encapsulated, 2kVA, 1 phase, 120x240V primary, 16/32V secondary, NEMA 3R, 115C rise Picture of 2S46F - Transformer, buck boost, encapsulated, 2kVA, 1 phase, 120x240V primary, 16/32V secondary, NEMA 3R, 115C rise
Picture of 2S46F - Transformer, buck boost, encapsulated, 2kVA, 1 phase, 120x240V primary, 16/32V secondary, NEMA 3R, 115C rise Picture of 2S46F - Transformer, buck boost, encapsulated, 2kVA, 1 phase, 120x240V primary, 16/32V secondary, NEMA 3R, 115C rise
Square D

2S46F - Transformer, buck boost, encapsulated, 2kVA, 1 phase, 120x240V primary, 16/32V secondary, NEMA 3R, 115C rise

Item Code: 587324
Category Miscellaneous
Manufacturer SCHNEIDER ELECTRIC
Manufacturer Ref 2S46F

Document
Document
Document
Watch video
Call for Availability
Add to Favorites
Compare

Description

A Buck and Boost Transformer is an insulating transformer with either a 120 V x 240 V primary with a 12/24 V or 16/32 V secondary, or a 240 V x 480 V primary with a 24/48 V secondary. A Buck and Boost Transformer is also useful in applications where the primary and secondary are interconnected for use as an autotransformer. The equipment enclosure is designed and constructed for indoor or outdoor use and is NEMA 3R rated. Square D Buck and Boost Transformers are UL and cUL listed (UL 506). Autotransformers can carry loads in excess of their nameplate rating. This Buck and Boost Transformer has a NEMA 3R rating, has a 120 x 240V primary voltage, and a 16/32V secondary voltage. This transformer has a rated power of 2KVA. This transformer has a temperature rise of 115 °C. This product has a UL listed, cULus & CSA certifications.
