Square D

8501XO80V02 - NEMA Control Relay, Type X, machine tool, 10A resistive at 600 VAC, 8 normally open contacts, 110/120 VAC 50/60 Hz coil

Category Miscellaneous
Picture of 8501XO80V02 - NEMA Control Relay, Type X, machine tool, 10A resistive at 600 VAC, 8 normally open contacts, 110/120 VAC 50/60 Hz coil
Square D

8501XO80V02 - NEMA Control Relay, Type X, machine tool, 10A resistive at 600 VAC, 8 normally open contacts, 110/120 VAC 50/60 Hz coil

Item Code: 32461
Category Miscellaneous
Manufacturer SCHNEIDER ELECTRIC
Manufacturer Ref 8501XO80V02

Document
Document
Document
Watch video
Call for Availability
Add to Favorites
Compare

Description

8501X NEMA machine tool relays combine a rugged heavy duty design with modular construction for greater flexibility. They are ideal for applications where long life, high reliability and ease of maintenance are important. This relay has a 10 ampere continuous current rating. It also has an A600 inductive contact rating. It has eight 8501XC1 contact cartridges. This relay has eight normally open contacts. The machine tool relays have straight through wiring. This makes wiring easier. The eight plug in contact cartridges in this relay make contact conversion or replacement very easy. Contact conversion or replacement can be done without removing any wiring. Relay has a 110/120 VAC 50/60 Hz coil. Relay is UL listed and CSA certified.
