Square D

8736SDO2V02S - NEMA starter, Type S, reversing, horizontal, Size 2, 45A, 25HP at 575VAC, 5kA SSCR, 3 phase, 3 pole, melting alloy overload, 120VAC coil, open [TAA]

Category Miscellaneous
Picture of 8736SDO2V02S - NEMA starter, Type S, reversing, horizontal, Size 2, 45A, 25HP at 575VAC, 5kA SSCR, 3 phase, 3 pole, melting alloy overload, 120VAC coil, open [TAA] Picture of 8736SDO2V02S - NEMA starter, Type S, reversing, horizontal, Size 2, 45A, 25HP at 575VAC, 5kA SSCR, 3 phase, 3 pole, melting alloy overload, 120VAC coil, open [TAA]
Picture of 8736SDO2V02S - NEMA starter, Type S, reversing, horizontal, Size 2, 45A, 25HP at 575VAC, 5kA SSCR, 3 phase, 3 pole, melting alloy overload, 120VAC coil, open [TAA] Picture of 8736SDO2V02S - NEMA starter, Type S, reversing, horizontal, Size 2, 45A, 25HP at 575VAC, 5kA SSCR, 3 phase, 3 pole, melting alloy overload, 120VAC coil, open [TAA]
Picture of 8736SDO2V02S - NEMA starter, Type S, reversing, horizontal, Size 2, 45A, 25HP at 575VAC, 5kA SSCR, 3 phase, 3 pole, melting alloy overload, 120VAC coil, open [TAA] Picture of 8736SDO2V02S - NEMA starter, Type S, reversing, horizontal, Size 2, 45A, 25HP at 575VAC, 5kA SSCR, 3 phase, 3 pole, melting alloy overload, 120VAC coil, open [TAA]
Picture of 8736SDO2V02S - NEMA starter, Type S, reversing, horizontal, Size 2, 45A, 25HP at 575VAC, 5kA SSCR, 3 phase, 3 pole, melting alloy overload, 120VAC coil, open [TAA] Picture of 8736SDO2V02S - NEMA starter, Type S, reversing, horizontal, Size 2, 45A, 25HP at 575VAC, 5kA SSCR, 3 phase, 3 pole, melting alloy overload, 120VAC coil, open [TAA]
Picture of 8736SDO2V02S - NEMA starter, Type S, reversing, horizontal, Size 2, 45A, 25HP at 575VAC, 5kA SSCR, 3 phase, 3 pole, melting alloy overload, 120VAC coil, open [TAA] Picture of 8736SDO2V02S - NEMA starter, Type S, reversing, horizontal, Size 2, 45A, 25HP at 575VAC, 5kA SSCR, 3 phase, 3 pole, melting alloy overload, 120VAC coil, open [TAA]
Square D

8736SDO2V02S - NEMA starter, Type S, reversing, horizontal, Size 2, 45A, 25HP at 575VAC, 5kA SSCR, 3 phase, 3 pole, melting alloy overload, 120VAC coil, open [TAA]

Item Code: 541548
Category Miscellaneous
Manufacturer SCHNEIDER ELECTRIC
Manufacturer Ref 8736SDO2V02S

Document
Document
Document
Watch video
Call for Availability
Add to Favorites
Compare

Description

Type S NEMA reversing magnetic starters are used for full voltage starting, stopping, and reversing AC squirrel cage motors. NEMA 8736 reversing starters are available in NEMA Sizes 00 to 7 and have ratings up to 810 amperes. NEMA reversing starters consist of two 8502S NEMA contactors that are mechanically and electrically interlocked and an overload relay. Sizes 0-5 reversing starters are available in either horizontal or vertical arrangements. This reversing starter is arranged horizontally. This 3 pole NEMA Size 2 reversing starter has an 45 ampere rating. This three phase NEMA Size 2 reversing starter has 10 HP at 200 VAC, 15 HP at 230 VAC and 25 HP at 460 and 575 VAC ratings. This reversing NEMA motor starter has a melting alloy type overload relay that uses Type B thermal units to sense over current conditions. This NEMA starter has a 5 kA maximum SCCR (Short Circuit Current Rating) per UL508A when protected by an appropriate circuit breaker or fuse. Type S motor starters are available with replaceable coils in a wide variety of voltages. This starter has a 110/120 VAC 50/60 Hz operating coil wired for separate control. This NEMA reversing starter is an open device without an enclosure. This starter is 8.50 inches tall, 9.00 inches wide and 6.03 inches deep. A wide variety of accessories are available for Type S starters. Type S reversing NEMA motor starters are UL listed and CSA certified.
