CA2KN31F7 - Control relay, TeSys K, 3 NO + 1 NC, lt or eq to 690V, 110VAC coil
Description
Specifications
0.39
2.6
2.42
2.57
For use with control circuit applications
Schneider Electric
USA
US
RELAY CTRL 10A 400HZ 110VAC 3NO-1NC SURF
TeSys Control Relays provide a cost-effective solution to a simple application
Same design as TeSys D, K and SK contactors
Different ways for connection (such as screw clamp terminal, spring terminal, welded on PCB)
Compatible for all the voltages on the market
Control relays for AC or DC control circuits (AC15, DC13)
Schneider Electric
2.6000
IN
2.5700
IN
1
11.8600
cu-in
0.3900
LB
2.4200
IN
Square D
IEC CONTROL RELAYS & ACCESSORIES
Amperage Rating
A
10
Temperature Rating
deg C
-20 To 50
Terminal Type
Screw clamp
Coil Voltage
V AC
110
Contact Form
3NO-1NC 3 Form A/1 Form B
Contact Rating
10 A at 600 V AC
Dimensions
45 mm W x 57 mm D x 58 mm H
Enclosure Type
IP2x
Frequency Rating
HZ
400
Mounting Type
Surface
Series
K Series
