Square D

EJB34025SA - Mini circuit breaker, E-Frame, 25A, 3 pole, 480Y/277 VAC, 100 kA max, bolt on, shunt trip [TAA]

Category Miscellaneous
Picture of EJB34025SA - Mini circuit breaker, E-Frame, 25A, 3 pole, 480Y/277 VAC, 100 kA max, bolt on, shunt trip [TAA] Picture of EJB34025SA - Mini circuit breaker, E-Frame, 25A, 3 pole, 480Y/277 VAC, 100 kA max, bolt on, shunt trip [TAA]
Picture of EJB34025SA - Mini circuit breaker, E-Frame, 25A, 3 pole, 480Y/277 VAC, 100 kA max, bolt on, shunt trip [TAA] Picture of EJB34025SA - Mini circuit breaker, E-Frame, 25A, 3 pole, 480Y/277 VAC, 100 kA max, bolt on, shunt trip [TAA]
Square D

EJB34025SA - Mini circuit breaker, E-Frame, 25A, 3 pole, 480Y/277 VAC, 100 kA max, bolt on, shunt trip [TAA]

Item Code: 1197794
Category Miscellaneous
Manufacturer SCHNEIDER ELECTRIC
Manufacturer Ref EJB34025SA

Document
Document
Document
Document
Call for Availability
Add to Favorites
Compare

Description

E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 25A, 3 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 100 kA max interrupt rating at 120 VAC. This device has a hold current of 270A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 875A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes a shunt trip. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.

Specifications

Weight

4

AD All Features

Used in lighting panelboards

AD Alternative Part Number

10935456

AD Application

For overload and short circuit protection

AD Brand (Description)

Square D

AD Country

USA

AD Country Of Origin

MX

AD Document Caption 1

Warranty Information

AD Document Caption 2

Catalog

AD Document Caption 3

Specification Sheet

AD Document Caption 4

Instruction/Installation Manual

AD Gtin

00785901648574

AD IDEA Index ID

10935456

AD Invoice Description

BREAKER CKT 480Y/277 VACVAC 25A 3 E 3PH

AD Item Features 01

Used in lighting panelboards

AD Item Features 02

From 15A to 125A ratings

AD Item Features 03

Troubleshoot faster with Visi-Trip

AD Keywords

EJB34025SA Type EJB Circuit Breaker, 480Y/277 VAC, 25 A, 100 kA at 240 VAC/65 kA at 480Y/277 VAC Interrupt, 3 Poles, Thermal Magnetic Trip ; Schneider Electric ; Square D ; EJB34025SA ; 785901648574 ; Lighting Panel Circuit Breakers

AD Manufacturer (Description)

Schneider Electric

AD Package Quantity

1

AD Package Weight

4.0000

AD Package Weight UOM

LB

AD Part Number Keywords

EJB34025SA ; 10935456 ; 785901648574 ; 78590164857 ; 00785901648574

Brand

Square D

Spec 1 Attribute

Amperage Rating

Spec 1 Attribute UOM

A

Spec 1 Attribute Value

25

Spec 10 Attribute

PHASE

Spec 10 Attribute Value

3

Spec 11 Attribute

Temperature Rating

Spec 11 Attribute UOM

deg F

Spec 11 Attribute Value

104

Spec 12 Attribute

Trip Range

Spec 12 Attribute UOM

A

Spec 12 Attribute Value

270 to 875

Spec 13 Attribute

Trip Type

Spec 13 Attribute Value

Thermal Magnetic

Spec 14 Attribute

Type

Spec 14 Attribute Value

Type EJB

Spec 15 Attribute

Voltage Rating

Spec 15 Attribute UOM

V AC

Spec 15 Attribute Value

480Y/277

Spec 16 Attribute

Wire Size

Spec 16 Attribute Value

12 to 6 AWG Al, 14 to 6 AWG Cu

Spec 2 Attribute

Connection Type

Spec 2 Attribute Value

Lug

Spec 3 Attribute

Dimensions

Spec 3 Attribute Value

5.8 in H x 2.94 in W x 4.05 in D

Spec 4 Attribute

Frame

Spec 4 Attribute Value

E

Spec 5 Attribute

Frequency Rating

Spec 5 Attribute UOM

HZ

Spec 5 Attribute Value

50/60

Spec 6 Attribute

Interrupt Rating

Spec 6 Attribute Value

100 kA at 240 VAC/65 kA at 480Y/277 VAC

Spec 7 Attribute

Material

Spec 7 Attribute Value

Thermoset Composite Resin

Spec 8 Attribute

Mounting Type

Spec 8 Attribute Value

Bolted-On

Spec 9 Attribute

Number Of Poles

Spec 9 Attribute Value

3
