Square D

JGL36000S25 - Automatic switch, PowerPacT J, 250A, 3 pole, 600VAC, 18kA, lugs, magnetic

Category Miscellaneous
Picture of JGL36000S25 - Automatic switch, PowerPacT J, 250A, 3 pole, 600VAC, 18kA, lugs, magnetic Picture of JGL36000S25 - Automatic switch, PowerPacT J, 250A, 3 pole, 600VAC, 18kA, lugs, magnetic
Picture of JGL36000S25 - Automatic switch, PowerPacT J, 250A, 3 pole, 600VAC, 18kA, lugs, magnetic Picture of JGL36000S25 - Automatic switch, PowerPacT J, 250A, 3 pole, 600VAC, 18kA, lugs, magnetic
Picture of JGL36000S25 - Automatic switch, PowerPacT J, 250A, 3 pole, 600VAC, 18kA, lugs, magnetic Picture of JGL36000S25 - Automatic switch, PowerPacT J, 250A, 3 pole, 600VAC, 18kA, lugs, magnetic
Picture of JGL36000S25 - Automatic switch, PowerPacT J, 250A, 3 pole, 600VAC, 18kA, lugs, magnetic Picture of JGL36000S25 - Automatic switch, PowerPacT J, 250A, 3 pole, 600VAC, 18kA, lugs, magnetic
Picture of JGL36000S25 - Automatic switch, PowerPacT J, 250A, 3 pole, 600VAC, 18kA, lugs, magnetic Picture of JGL36000S25 - Automatic switch, PowerPacT J, 250A, 3 pole, 600VAC, 18kA, lugs, magnetic
Square D

JGL36000S25 - Automatic switch, PowerPacT J, 250A, 3 pole, 600VAC, 18kA, lugs, magnetic

Item Code: 597993
Category Miscellaneous
Manufacturer SCHNEIDER ELECTRIC
Manufacturer Ref JGL36000S25

Document
Document
Document
Document
Watch video
Call for Availability
Add to Favorites
Compare

Description

PowerPacT J-Frame automatic switches are a disconnect device and can be used to open and close a circuit under normal operating conditions. The automatic switches are similar in construction, use the same accessories, and offer the same connection possibilities as the J-Frame circuit breaker version. The switches have a factory set, nonadjustable trip point calibrated to protect the molded case switch. The automatic switch can make and break its rated current. PowerPacT J-Frame switches are available in unit mount, I-Line, plug in, or drawout constructions. This switch has lugs on both the line and load sides. This PowerPacT J, 250A, 3 pole, automatic switch has a short circuit withstand current rating of 18kA at 600VAC. PowerPacT J automatic switches comply to UL, CSA, ANCE, and IEC standards.
