Square D

LA36250 - Circuit breaker, LA, 250A, 3 pole, 600VAC, 22kA, 250VDC, 10kA, I-Line, thermal magnetic

Category Miscellaneous
Picture of LA36250 - Circuit breaker, LA, 250A, 3 pole, 600VAC, 22kA, 250VDC, 10kA, I-Line, thermal magnetic Picture of LA36250 - Circuit breaker, LA, 250A, 3 pole, 600VAC, 22kA, 250VDC, 10kA, I-Line, thermal magnetic
Picture of LA36250 - Circuit breaker, LA, 250A, 3 pole, 600VAC, 22kA, 250VDC, 10kA, I-Line, thermal magnetic Picture of LA36250 - Circuit breaker, LA, 250A, 3 pole, 600VAC, 22kA, 250VDC, 10kA, I-Line, thermal magnetic
Picture of LA36250 - Circuit breaker, LA, 250A, 3 pole, 600VAC, 22kA, 250VDC, 10kA, I-Line, thermal magnetic Picture of LA36250 - Circuit breaker, LA, 250A, 3 pole, 600VAC, 22kA, 250VDC, 10kA, I-Line, thermal magnetic
Picture of LA36250 - Circuit breaker, LA, 250A, 3 pole, 600VAC, 22kA, 250VDC, 10kA, I-Line, thermal magnetic Picture of LA36250 - Circuit breaker, LA, 250A, 3 pole, 600VAC, 22kA, 250VDC, 10kA, I-Line, thermal magnetic
Picture of LA36250 - Circuit breaker, LA, 250A, 3 pole, 600VAC, 22kA, 250VDC, 10kA, I-Line, thermal magnetic Picture of LA36250 - Circuit breaker, LA, 250A, 3 pole, 600VAC, 22kA, 250VDC, 10kA, I-Line, thermal magnetic
Square D

LA36250 - Circuit breaker, LA, 250A, 3 pole, 600VAC, 22kA, 250VDC, 10kA, I-Line, thermal magnetic

Item Code: 567696
Category Miscellaneous
Manufacturer SCHNEIDER ELECTRIC
Manufacturer Ref LA36250

Document
Document
Document
Document
Document
Call for Availability
Add to Favorites
Compare

Description

Square D™-brand I-Line™ circuit breaker power distribution panelboards are for use on AC or DC systems. The panels, labeled cULus (compliance to UL and CSA standards certified by UL) are also Underwriters Laboratories® (UL®) Listed under File E33139. The following are suitable for use as service entrance equipment such as all main circuit breaker panelboards. I-Line circuit breaker panelboards are available as 400–1200 A main lugs only and 100–1200 A main circuit breakers. I-Line circuit breaker panelboards are designed, manufactured, and tested to comply to UL, CSA, NFPA, NEMA & W-P standards. This I-Line, circuit breaker is a 3P breaker with a rated current of 250A. This product has a breakning capacity of 2 kA@600VAC. This breaker has a thermal-magnetic trip unit trechnology. This product complys to UL listed & CSA standards. With a magnetic hold current of 1250A and a magnetic tripping current of 2500A. Dimensions for this product are 11 in (H), 6 in (W), 5.84 in (D).
