Schneider Electric

LP1K0910BD3 - Contactor, TeSys K, 3P, AC-3, lt or eq to 440V, 9A, 1 NO aux, 24VDC coil

Picture of LP1K0910BD3 - Contactor, TeSys K, 3P, AC-3, lt or eq to 440V, 9A, 1 NO aux, 24VDC coil
Schneider Electric

LP1K0910BD3 - Contactor, TeSys K, 3P, AC-3, lt or eq to 440V, 9A, 1 NO aux, 24VDC coil

Item Code: 811129
Manufacturer SCHNEIDER ELECTRIC
Manufacturer Ref LP1K0910BD3

Document
Document
Document
Call for Availability
Add to Favorites
Compare

Description

LP1K0910BD3 from Schneider Electric is a 3-pole TeSys K contactor for motor applications up to 4kW@400V. It provides a 24V DC coil with surge suppressor, 1NO built-in auxiliary contact, connection by screw clamp terminals. Very compact, DIN-rail mounting and screw fixing, it procures reliability and durability to standard applications. Available worldwide, multi-standards certified (IEC, UL, CSA, CCC, EAC). Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC).

Specifications

Weight

0.49lb

Height

58mm

Width

1.87mm

Length

2.42mm

Depth

57mm

AD 360 Spin URL

https://spin.adhq.com/Schneider%20Electric/LP1K0910BD3/LP1K0910BD3.spin

AD All Features

One of the smallest contactor offerings in the market

AD Alternative Part Number

8024014

AD Application

For motor control and resistive loads

AD Brand (Description)

Schneider Electric

AD Country

USA

AD Country Of Origin

FR

AD Document Caption 1

RoHS

AD Document Caption 2

Specification Sheet

AD Document Caption 3

Owners/User Manual

AD EAN

3389110428513

AD Gtin

03389110428513

AD IDEA Index ID

8024014

AD Invoice Description

CONTACTOR IEC 690VAC 9/16/20A 3W 3 3NO

AD Item Features 01

One of the smallest contactor offerings in the market

AD Keywords

Square D TeSys K LP1K0910BD3 K-Line IEC Contactor, 690 VAC V Coil, 9/16/20 A, 3NO Contact, 3 Poles ; Schneider Electric ; Schneider Electric ; LP1K0910BD3 ; 785901105565 ; NEMA & IEC Contactors

AD Manufacturer (Description)

Schneider Electric

AD Package Height UOM

IN

AD Package Length

2.4200

AD Package Length UOM

IN

AD Package Quantity

1

AD Package Weight

0.4900

AD Package Weight UOM

LB

AD Package Width

1.8700

AD Package Width UOM

IN

AD Part Number Keywords

LP1K0910BD3 ; 8024014 ; 785901105565 ; 78590110556 ; 03389110428513 ; 3389110428513

Brand

Square D

Spec 1 Attribute

Coil Power Rating

Spec 1 Attribute UOM

W

Spec 1 Attribute Value

3

Spec 10 Attribute

Mounting Type

Spec 10 Attribute Value

Rail/Surface

Spec 11 Attribute

Number of Auxiliary Contacts

Spec 11 Attribute Value

1NO

Spec 12 Attribute

Number Of Poles

Spec 12 Attribute Value

3

Spec 13 Attribute

Operating Cycles

Spec 13 Attribute UOM

Cycles/hr

Spec 13 Attribute Value

3600

Spec 14 Attribute

Operating Temperature

Spec 14 Attribute UOM

deg C

Spec 14 Attribute Value

-25 To 50

Spec 15 Attribute

Series

Spec 15 Attribute Value

LP1K

Spec 16 Attribute

Size

Spec 16 Attribute UOM

MM

Spec 16 Attribute Value

45/57/58

Spec 17 Attribute

Terminal Type

Spec 17 Attribute Value

Screw clamp

Spec 18 Attribute

Type

Spec 18 Attribute Value

K-Line

Spec 2 Attribute

Coil Voltage

Spec 2 Attribute UOM

V AC

Spec 2 Attribute Value

690

Spec 3 Attribute

Connection Type

Spec 3 Attribute Value

Screw clamp

Spec 4 Attribute

Contact Configuration

Spec 4 Attribute Value

3NO

Spec 5 Attribute

Contact Rating

Spec 5 Attribute Value

20/50 A at 600 V AC, 10/50 A at 600 V AC

Spec 6 Attribute

Dimensions

Spec 6 Attribute Value

45 mm W x 57 mm D x 58 mm H

Spec 7 Attribute

Enclosure Type

Spec 7 Attribute Value

Open

Spec 8 Attribute

Frequency Rating

Spec 8 Attribute UOM

HZ

Spec 8 Attribute Value

50/60

Spec 9 Attribute

Maximum Load Current

Spec 9 Attribute UOM

A

Spec 9 Attribute Value

9/16/2020
