ZB5AZ101 - Harmony, 22mm Push Button, XB5A operators, contact block, with mounting collar, 1 NO, screw clamp terminal

Picture of ZB5AZ101 - Harmony, 22mm Push Button, XB5A operators, contact block, with mounting collar, 1 NO, screw clamp terminal Picture of ZB5AZ101 - Harmony, 22mm Push Button, XB5A operators, contact block, with mounting collar, 1 NO, screw clamp terminal
Picture of ZB5AZ101 - Harmony, 22mm Push Button, XB5A operators, contact block, with mounting collar, 1 NO, screw clamp terminal Picture of ZB5AZ101 - Harmony, 22mm Push Button, XB5A operators, contact block, with mounting collar, 1 NO, screw clamp terminal
Picture of ZB5AZ101 - Harmony, 22mm Push Button, XB5A operators, contact block, with mounting collar, 1 NO, screw clamp terminal Picture of ZB5AZ101 - Harmony, 22mm Push Button, XB5A operators, contact block, with mounting collar, 1 NO, screw clamp terminal
Picture of ZB5AZ101 - Harmony, 22mm Push Button, XB5A operators, contact block, with mounting collar, 1 NO, screw clamp terminal Picture of ZB5AZ101 - Harmony, 22mm Push Button, XB5A operators, contact block, with mounting collar, 1 NO, screw clamp terminal
Picture of ZB5AZ101 - Harmony, 22mm Push Button, XB5A operators, contact block, with mounting collar, 1 NO, screw clamp terminal Picture of ZB5AZ101 - Harmony, 22mm Push Button, XB5A operators, contact block, with mounting collar, 1 NO, screw clamp terminal
Schneider Electric

ZB5AZ101 - Harmony, 22mm Push Button, XB5A operators, contact block, with mounting collar, 1 NO, screw clamp terminal

Item Code: 1255400
Manufacturer SCHNEIDER ELECTRIC
Manufacturer Ref ZB5AZ101

Document
Document
Document
Document
Watch video
Call for Availability
Add to Favorites
Compare

Description

Harmony 22 mm modular push buttons, selector switches, pilot lights are designed for industry. This range combines simplicity of setup, flexibility and a robust construction. An ingenious locking system consisting of a snap fit head and body that can be tightened with a single screw but still ensuring an easy and yet secure mounting. Harmony XB4/ZB4 are 22 mm chromium plated metal modular push buttons, selector switches and pilot lights connecting to fully metal mounting collar. The operators can be purchased as complete operators or various modules that can be assembled to meet the user’s specific requirement. Harmony XB5/ZB5 are 22 mm plastic modular push buttons, selector switches, pilot lights. The operator can have a round and square plastic bezel. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product. The contacts can be used for low load electrical contact and high power applications. Shake proof connection screws make periodic retightening unnecessary. A complete set of accessories to provide a solution for applications where exposure to high pressure cleaning, dust and extreme temperatures is an everyday occurrence. These harmony 22mm push buttons are used by machine manufacturers (automotive, textiles, timber) and control system panel builders. Certified and approved for meeting requirements throughout all continents: EN/IEC, UL, NEMA, CSA, CCC, Gost, JIS and many more. They have UL and CE markings and have ratings up to IP66 and IP69K.

Specifications

Weight

0.04lb

Width

1.33mm

Length

2.11mm

AD 360 Spin URL

https://spin.adhq.com/Schneider%20Electric/ZB5AZ101/ZB5AZ101.spin

AD Alternative Part Number

8012443

AD Application

Electrical Component

AD Brand (Description)

Schneider Electric

AD Country

USA

AD Country Of Origin

FR

AD Document Caption 1

RoHS

AD Document Caption 2

Specification Sheet

AD Document Caption 3

Owners/User Manual

AD Document Caption 4

Full Engineering Drawing

AD EAN

3389110924398

AD Gtin

03389110924398

AD IDEA Index ID

8012443

AD Invoice Description

COMPLETE BODY/CONTACT ASSEMBLY 22MM 1NO

AD Item Features 01

Quick and easy assembly and disassembly

AD Item Features 02

Robustness to withstand harsh environments

AD Item Features 03

With various types of connection - screw clamp, connector, Faston connector, spring terminal, or printed circuit board

AD Item Features 04

Excellent mechanical connection with operator head

AD Item Features 05

A large set of accessories to customize your panels

AD Keywords

Harmony ZB5AZ101 Complete Body/Contact Assembly, 22 mm, 1NO Contact, 10 A at 600 V AC Contact, Silver Alloy Contact, Momentary Action, Black/Green ; Schneider Electric ; Schneider Electric ; ZB5AZ101 ; 785901370215 ; Pushbutton & Switch Contact Blocks

AD Manufacturer (Description)

Schneider Electric

AD Package Height UOM

IN

AD Package Length

2.1100

AD Package Length UOM

IN

AD Package Quantity

1

AD Package Weight

0.0400

AD Package Weight UOM

LB

AD Package Width

1.3300

AD Package Width UOM

IN

AD Part Number Keywords

ZB5AZ101 ; 8012443 ; 785901370215 ; 78590137021 ; 03389110924398 ; 3389110924398

AD Video Links

https://www.youtube.com/embed/6sW9Z3A8tM0

Brand

Square D

Spec 1 Attribute

Action

Spec 1 Attribute Value

Momentary

Spec 10 Attribute

Operator Type

Spec 10 Attribute Value

Slow Break

Spec 11 Attribute

Series

Spec 11 Attribute Value

ZB5

Spec 12 Attribute

Size

Spec 12 Attribute UOM

MM

Spec 12 Attribute Value

22

Spec 13 Attribute

Terminal Type

Spec 13 Attribute Value

Screw clamp

Spec 2 Attribute

Color

Spec 2 Attribute Value

Black/green

Spec 3 Attribute

Contact Configuration

Spec 3 Attribute Value

1NO

Spec 4 Attribute

Contact Material

Spec 4 Attribute Value

Silver Alloy

Spec 5 Attribute

Contact Rating

Spec 5 Attribute Value

10 A at 600 V AC

Spec 6 Attribute

Contacts

Spec 6 Attribute Value

1

Spec 7 Attribute

Dimensions

Spec 7 Attribute Value

1.18 in W x 1.26 in D x 1.65 in H

Spec 8 Attribute

Enclosure Type

Spec 8 Attribute Value

IP20

Spec 9 Attribute

Material

Spec 9 Attribute Value

Plastic
