Universal

C218UNVME000K - Compact Fluorescent Electronic Ballast

Category Electronic Compact Fluorescent Ballasts
Picture of C218UNVME000K - Compact Fluorescent Electronic Ballast Picture of C218UNVME000K - Compact Fluorescent Electronic Ballast
Picture of C218UNVME000K - Compact Fluorescent Electronic Ballast Picture of C218UNVME000K - Compact Fluorescent Electronic Ballast
Picture of C218UNVME000K - Compact Fluorescent Electronic Ballast Picture of C218UNVME000K - Compact Fluorescent Electronic Ballast
Universal

C218UNVME000K - Compact Fluorescent Electronic Ballast

Item Code: 308379
Category Electronic Compact Fluorescent Ballasts
Manufacturer Ref C218UNVME000K

Document
Document
Call for Availability
Add to Favorites
Compare

Description

Compact Fluorescent Electronic Ballast; Type High Frequency; Starting Type Programmed; Circuit Type HPF; Lamp Type CFQ18W/G24Q, CFM18W/GX24Q, CFS21W/GR10Q; Lamp Style Quad/Triple Tube; Number of Lamps 1 or 2; Lamp Wattage 18/21 W; Input Voltage 120/277 V; Input Current 0.3/0.16/0.32/0.17/0.37/0.18 Ampere at 120 VAC, 0.13/0.07/0.14/0.16/0.08 Ampere at 277 VAC; Input Power 35/19/38/20/43/24 W; Frequency Rating 50/60 Hz; Power Factor 0.98/0.95; Ballast Factor 0.95/0.98/1; Maximum THD 10/15 Percent; Minimum Starting Temperature 0 Deg F; Wiring Series; Lead Configuration Multi Exit; Size 4.94 Inch L x 2.31 Inch W x 1 Inch H; Approval UL (Canada and US), CSA; Color Black; Can Material Metal; Packaging Container Type Multi-E Kit

Specifications

Weight

0.57lb

AD All Features

High power factor

AD Application

Outdoor Applications

AD Brand (Description)

Universal

AD Country

USA

AD Country Of Origin

US

AD Includes

Multi-Exit Ballast, Snap-Mount Adapter Plate, Lead Wire Set, Wire Extraction Tool, Instructions

AD Invoice Description

BALLAST ELEK COMPACT FLUOR CFL 18W 35W 2

AD Item Features 01

High power factor

AD Manufacturer (Description)

Universal Douglas

AD Package Quantity

1

Brand

Universal Ballast

Category

ELECTRONIC COMPACT FLUORESCENT BALLASTS

Spec 1 Attribute

Amperage Rating

Spec 1 Attribute UOM

A

Spec 1 Attribute Value

0.13 to 0.368

Spec 10 Attribute

Minimum Starting Temperature

Spec 10 Attribute UOM

deg F

Spec 10 Attribute Value

-18

Spec 11 Attribute

Number of Lamps

Spec 11 Attribute Value

2

Spec 12 Attribute

Power Factor

Spec 12 Attribute Value

0.98

Spec 13 Attribute

Start Type

Spec 13 Attribute Value

PROGRAMMED

Spec 14 Attribute

Thermal Protection

Spec 14 Attribute Value

CLASS P

Spec 15 Attribute

Total Harmonic Distortion

Spec 15 Attribute UOM

%

Spec 15 Attribute Value

<10

Spec 16 Attribute

Voltage Rating

Spec 16 Attribute UOM

V AC

Spec 16 Attribute Value

120 To 277

Spec 17 Attribute

Wattage

Spec 17 Attribute UOM

W

Spec 17 Attribute Value

35

Spec 2 Attribute

Ballast Factor

Spec 2 Attribute Value

0.95

Spec 3 Attribute

Color

Spec 3 Attribute Value

White

Spec 4 Attribute

Dimensions

Spec 4 Attribute Value

4.94 in L x 2.31 in W x 1 in H

Spec 5 Attribute

Dimmable

Spec 5 Attribute Value

Non-Dimmable

Spec 6 Attribute

Enclosure Type

Spec 6 Attribute Value

NEMA 1

Spec 7 Attribute

Frequency Rating

Spec 7 Attribute UOM

HZ

Spec 7 Attribute Value

50/60

Spec 8 Attribute

Lamp Base Type

Spec 8 Attribute Value

4-Pin G24q

Spec 9 Attribute

Lamp Wattage

Spec 9 Attribute UOM

W

Spec 9 Attribute Value

18
